3 Unleashing the potential of the Internet of Things

capabilities include capabilities for content management, the service dispatcher and access control.
Details can be found in clause 11.
NOTE 2 – Although not shown in Figure 6-1, MOC capabilities in NGN can also interact with other
applications outside the MOC service domain, such as social network services (SNS) or blog applications,
which can make MOC related information available in accordance with customer or application
requirements.
The MOC service domain includes MOC applications. MOC applications run the application logic
and use MOC capabilities accessible via standard interfaces.
NOTE 3 – Although not shown in Figure 6-1, MOC capabilities and MOC applications can also exist in the
MOC device domain.

6.2 Types of machine-oriented communications
MOC covers communications among MOC devices and humans, specifically:

– communications among different MOC devices and among MOC devices and MOC
applications;
– communications among MOC devices and other devices controlled by humans.

The first type of communications deals with data collection, device management, device operations
and other communication functions with remote equipment. These communications are used in
many scenarios, e.g., that of MOC applications getting the relevant information provided by
sensors.

The second type of communications may be initiated by remote MOC devices to timely inform
humans about relevant information detected in MOC devices, or may be initiated by humans to get
relevant information from remote MOC devices. These communications involve many scenarios,
e.g., a human connecting to a surveillance camera in his house by using a mobile phone.
In the case of an MOC device interacting with MOC capabilities in a network domain or with MOC
applications, the execution of an MOC application in an NGN environment may be divided into the
following phases:
• Data collection: the MOC device detects, measures and records data (e.g., data related to
physical properties, multimedia data, etc.). When the MOC device meets a trigger threshold
or receives an instruction from MOC capabilities in the network domain or MOC
applications, the MOC device requests the NGN to transfer the data to the MOC
application.
NOTE 1 – The MOC device follows the pre-configured policy, which can be decided by the MOC
capabilities or the MOC applications. According to the policy, the MOC device detects data,
executes the logic, and initiates the communication to the MOC applications or human-controlled
MOC devices to report the relevant information.
• Data transportation: the NGN establishes a data path between the MOC device and the
MOC capabilities. The MOC application can communicate with the MOC device directly
(without gateway) under the authorization of the MOC capabilities in NGN: in order to
manage the MOC device, the MOC application gets the authorization information from the
MOC capabilities which are used for the secure communication's authorization and session
key negotiation.

NOTE 2 – The MOC device may also initiate such a process.
• Data analysis: the MOC application analyses data received from the MOC device. MOC
capabilities in NGN can also analyse the data based on rules defined by MOC end users.
• Service delivery: the MOC application executes the service logic and decides how to
publish the information to MOC end users (including MOC devices, humans or other
applications). Information delivery can be "active" meaning that the MOC application

264 Rec. ITU-T Y.4109/Y.2061 (06/2012)
