 Mail_address. 5. CONSIDERATION
 Phone_number.
We consider how our system makes up for a shortage of
The patient table has almost all the same keys as the physiotherapists. Since TRS is useful for patients who
operator table, except operator_ID is changed to patient_ID. undergo home-visit rehabilitation, we compare TRS with
Frames in a file that were bookmarked by an operator home-visit rehabilitation.
are managed with the following keys: In TRS, a patient is coached by an operator instead of a
 Auto_ID. physiotherapist, and a physiotherapist supervises multiple
 Bookmark_ID. operators. Moreover, an operator’s salary is a fraction of a
 Start frame number. physiotherapist’s one. Therefore, a physiotherapist’s salary
 End frame number. can be used to pay multiple operators to coach multiple
An E-R diagram for these tables is shown in Figure 15. patients in TRS.
A supervisor can search for measured/archived files with the The number of patients that can be coached using a
patient_ID and/or the stored_date. physiotherapist’s salary in TRS Nps is as follows:

N ps = N m * N o / (1 + N m * S o/S p) (1)

where N m is the number of operators that a
physiotherapist supervises, N o is the number of patients that
an operator coaches in one hour, S p is a physiotherapist’s
salary, and S o is an operator’s salary.

We assume that a physiotherapist and an operator coach
a patient for 90 and 45 minutes, respectively. Therefore:

N o = 2 * N p (2)

N p is the number of patients that a physiotherapist
coaches in one hour. The ratio between N ps and N p is as
follows:
Figure 15. E-R diagram to manage files
N ps/N p = 2 * N m/ (1 + N m * S o/S p) (3)
4.4.4. Replaying tool
A supervisor can replay the content of selected files by N ps/N p is calculated and shown in Figure 17. When a
clicking them. It is possible to select view items such as physiotherapist supervises five operators and his or her
camera view, line between joints, and joint points. We made salary is five times that of an operator, five times as many
a seek bar in addition to a replay button, a stop button, and patients are coached in TRS as in home-visit rehabilitation.
arrow buttons, as shown in Figure. 16. A supervisor can TRS is very useful for overcoming a shortage of
easily check measured data in the selected frame. physiotherapists. However, a patient has to pay about $1500

to buy a PC and install Microsoft KINECT. It is difficult to
evaluate whether this is expensive or not because a PC can
be used for other tasks, and a physiotherapist needs an
automobile to visit a patient for home-visit rehabilitation.

Figure 16. Screenshot of the replaying tool

Figure 17. Effect for shortage of physiotherapist in TRS

– 146 –
